Brand Name : | JZTG |
Model Number : | Cleaning drilling bucket |
Certification : | CE,ISO,IAF,CQC |
Price : | Negotiable |
Payment Terms : | T/T, L/C, Western Union |
Supply Ability : | 1500pcs per month |
Delivery Time : | 3-10days |
Blue Double Shell Roller Bits Core Barrel Q345 Custom Size Demand
Double Shell Roller Bits Drilling bucket Core Barrel Q345 any size demand
♥ Inner shell drilling first, the outter follow, Cutting ring with rock drilling bits rock;
♥ Rock drilling bits perform stage breaking and drilling ;
♥ Small barrel facilitates the coring operation; large barrel performs stage breaking;
♥ Applicable layers: gravel, boudler, medium weathered rock.
Drilling Tool Model | |||||||
Model | Size | Height | Bucket Thickness | Upper Bottom Thickness | Lower Bottom Thickness | No of teeth | Weight |
Cleaning Bucket | φ600 | 800 | 16 | 40 | 200 | / | 432 |
φ700 | 800 | 16 | 40 | 200 | / | 513 | |
φ800 | 800 | 16 | 40 | 200 | / | 622 | |
φ900 | 800 | 16 | 40 | 200 | / | 724 | |
φ1000 | 800 | 16 | 40 | 200 | / | 837 | |
φ1100 | 800 | 16 | 40 | 200 | / | 959 | |
φ1200 | 800 | 16 | 40 | 200 | / | 1086 | |
φ1250 | 800 | 16 | 40 | 200 | / | 1154 | |
φ1300 | 800 | 16 | 40 | 200 | / | 1242 | |
φ1400 | 800 | 16 | 40 | 200 | / | 1392 | |
φ1500 | 600 | 16 | 40 | 200 | / | 1477 | |
φ1600 | 600 | 16 | 40 | 200 | / | 1649 | |
φ1700 | 600 | 16 | 40 | 200 | / | 1826 | |
φ1800 | 600 | 16 | 50 | 200 | / | 2293 | |
φ1900 | 600 | 16 | 50 | 200 | / | 2518 | |
φ2000 | 600 | 20 | 50 | 200 | / | 3046 | |
φ2200 | 600 | 20 | 50 | 200 | / | 3481 | |
φ2500 | 600 | 20 | 50 | 200 | / | 4392 | |
φ2800 | 600 | 20 | 50 | 200 | / | 5607 | |
φ3000 | 600 | 20 | 50 | 200 | / | 6377 | |
Kelly Box | suit for any brand machine | Bauer--200 | Bauer--250 | ||||
Remark1: Size refers to diameter of bore hole, all measurements in millimeters (mm); weight in kilograms(kg); Remark2: Customers can consultative our engineers to confirm the drilling bucket selection according to the construction geological, while drill bucket can be customized according to customer demand. |
Quality Service :
![]() |
